Product Introduction

This chassis is assembled from profiles (upper and lower cover plates, side panels, front and rear crossbeams, etc.), and the surface is sprayed with plastic< br /> The size of the chassis can be customized according to requirements, with holes and can be equipped with aluminum alloy handles< br /> The profile is formed by stretching aluminum alloy and sprayed with plastic on the surface< br /> Panel 1.8mm, side panel 1.2mm, upper and lower panels 1.5mm, surrounded by aluminum profiles, surface spray painted< br /> The upper and lower cover plates can open heat dissipation holes< br /> The chassis can be equipped with a separate lining board< br /> Chassis components: upper and lower cover plates, front and rear panels, left and right side panels, 4 pillars, 4 cover plates, and 8 screws.

Product Specification Table

Product model
 Dimensions (height x width x depth)
 Front and rear panel dimensions
 Left and right boards
 Upper and lower boards
KBC-1
 105*267*220
 90*240
 80*121
 182.5*121
KBC-2
 105*307*260
 90*280
 80*161
 222.5*161
KBC-3
 105*347*300
 90*320
 80*201
 262.5*201
KBC-4
 125*307*260
 110*280
 100*161
 222.5*161
KBC-5
 125*347*300
 110*320
 100*201
 262.5*201
KBC-6
 125*387*340
 110*360
 100*241
 302.5*241
KBC-7
 145*347*300
 130*320
 120*201
 262.5*201
KBC-8
 145*387*340
 130*360
 120*241
 302.5*241
KBC-9
 145*427*380
 130*400
 120*281
 342.5*281
KBC-10
 165*387*340
 150*360
 140*241
 302.5*241
KBC-11
 165*427*380
 150*400
 140*281
 342.5*281
KBC-12
 165*467*420
 150*440
 140*321
 382.5*321
KBC-13
 185*427*380
 170*400
 160*281
 342.5*281
KBC-14
 185*467*420
 170*440
 160*321
 382.5*321
KBC-15
 185*507*460
 170*480
 160*361
 422.5*361
KBC-16
 215*507*460
 200*480
 190*361
 422.5*361
KBC-17
 125*320*280
 110*293
 100*181
 235.5*181
KBC-18
 200*440*400
 185*413
 175*301
 312*301
KBC-19
 165*380*320
 150*353
 140*221
 295.5*221
KBC-20
 185*400*350
 170*370
 160*251
 315.5*251
