210

Product Introduction

1. Product labeling: The dimensions of the chassis are high, wide, and deep. Customizable (handle not required. Can be processed for punching, screen printing, laser marking, please consult customer service for details)
2. The chassis consists of 2.5mm front and rear panels, upper and lower covers, left and right side panels, aluminum profiles, aluminum handles, and rubber feet. The product dimensions are marked as outer diameter, excluding the thickness of handles and front and rear panels. The side panel is designed with rectangular heat dissipation holes.

Product Specification Table

Product model
Size (height x width x depth) mm
Panel size mm
210-1
80*220*260
80*220
210-2
100*260*260
100*260
210-3
120*320*260
120*320
210-4
140*340*260
140*340
210-5
160*360*260 160*360
210-6
160*360*280
160*360
210-7
140*360*280
140*360
210-8
160*160*240
160*160
210-9
180*400*350
180*400
210-10
200*420*380
200*420
210-11
200*150*260
200*150
210-12
150*150*200
150*150
210-13
120*120*200
120*120
210-14
160*340*280
160*340
210-15
140*340*280
140*340
